TAH 161-236LL) / Nordson 7700846 Static Mixer (nozzles) for Air Spraying

Description: Static Mixer (nozzles) for Air Spraying

Nordson Quick Spray disposable plastic static mixer nozzles 7700920 is used for low-pressure air-assisted spray system for two-component coatings. This disposable static mixer is designed for use with conventional meter/mix equipment or with Nordson’s two-component cartridge system.

Static Mixer 7700846 Specifications

Property Value Property Value
Product 7700846 Element Material Polypropylene
Old Product Number TAH 160-624AA-4 Housing Material Polypropylene
# of Elements: 24 Tip Style Air Cap Assembly***
ID inch 0.24 Max Housing Pressure* 360
ID mm 6.3 Max Housing Pressure** 25
Length inch
Length cm

*psi at 75°F
**bar at 30°C

10 Nordson series 160AA quick spray mixing nozzles
